2.0 SN1547

Year of production: 2025

Product code: ARIA20V24.R1

Frame angle: Angle 93° - Open frame (FRM93)

Seat width (SW): 400

Seat depth (SD): 420

Seat length (SL): 400

Seat to footrest (STF): 120

Camber Rear Wheels (CRW): 3

Center of Gravity (CG): 100

Frame color: Graphite grey (GG)

Frame type: Standard frame (STDF)

Rear wheels axle: Black matte painted aluminium (AXALSTD20)

Seat height rear (SHR) - op.A: 400

Seat height front (SHF) - op.A: 490

Seat type: Carbon fibre seat pan with tilting system (CARBTS)

Backrest system: Folding backrest with adjustable angle (BKRUF1)

Backrest angle (BRA): 90

Backrest height (BRH): 345

Backrest type: Aria® tension straps backrest (BKRTT1)

Knee to heel length (KHL) - op.B: 400

Footrest: Flexion-extension adjustable footrest (FOOTA2)

Code KITBR: Brakes kit consisting of:

Brakes support: Aluminium standard clamp (BRKASL2)

Brakes: Scissor lock (BRKOSL + BRKOSR)

Code KITRW: Rear wheels kit consisting of:

Rear wheels dimensions: 24 ′′

Rear wheels type: Black Wheel with black hub and black spokes (RWHAG)

Handrim 24'', 6 Tab Mounting: Carbo Life Curve L (HDRCFC)

Tyre 24x1.00: Schwalbe Right Run - Black/Grey (WTSWR)

Code KITFC: Forks and front casters kit consisting of:

Forks: Aria® Double - Sided - black anodized aluminium (FRKDS2)

Front casters: 4′′ Black aluminium (FRWH4)

Code SDG20: Side guards kit consisting of:

Side guards / Armrests: Black ABS Fendered (SDAL1)

Seat cushion: None

Push handles: None

Closable Anti tipper (ATPRS) - left mounted: Yes

Under-seat bag / Handle: None

Calf band: Calf band, height 8 cm - black textile (CLFB8)

Pair of frame protection - black eco-leather (FRMP): Yes

Backpack cordura and textile (BKPY): Yes

Owner's manual language: EN

Configuration price: 4370€
